VXI Backplanes

The specification governing VXIbus – an acronym for VMEbus eXtension for Instrumentation – defines the use of 4 x bus module sizes (fig.1), with the “A” and “B” modules being the same as 3U & 6U VMEbus cards. Although the VXI specification, broadly speaking, follows the VME standards, it includes defined functions on the P2 conneector and a further set of functions on the P3 connector. The most important variation in the two standards arises from the fact that any VXIbus instruments incorporated in a system must be capable of being physically screened against EMC on all sides with a provision for additional chassis screening between instruments.

Download Catalogue

VXI - Standard

Description Dimensions Order Code
“C” Size, 5 slot 262.0 x 152.4cm 927-4001364
“C” Size, 6 slot 262.0 x 182.88cm 927-4001365
“C” Size, 13 slot 262.0 x 395.0cm 927-4001366
“D” Size, 5 slot 395.0 x 152.4cm 927-4001367
“D” Size, 13 slot 395.0 x 395.0cm 927-4001368

VXI - High Power

Description Dimensions Order Code
“C” Size, 13 slot 1.9KW 927-4001369
“D” Size, 13 slot 3.0KW 927-4001370
